iPF6450
• If the Spectrophotometer Eject Guide is lowered while the
optional Spectrophotometer Unit is mounted, open the
Important
Spectrophotometer Unit Cover and lift up the central part
(near the blue label) of the Up-down Unit.
Lifting up the ends of the Up-down Unit may cause dam-
age.
• If the Spectrophotometer Unit is mounted, grasp the blue handles
on the left and right sides of the Spectrophotometer Eject Guide and
Note
remove the Spectrophotometer Eject Guide from the Spectropho-
tometer Unit.
3
Pull out the used Maintenance Cartridge by the grip (a).
Holding the cartridge by the handles (b) on both sides,
keep the cartridge level as you remove it.
•
Used Maintenance Cartridges are heavy. Remove and store the used Maintenance Cartridge, making sure to keep
it secure and level. If you drop a used Maintenance Cartridge or store it an angle, ink may leak and cause stains.
Important
•
The remaining Maintenance Cartridge capacity is stored on each printer. Do not install a used Maintenance Car-
tridge in another printer.
• If the printer has a Spectrophotometer Unit, look under the
Spectrophotometer Unit to check the position of the Mainte-
Note
nance Cartridge before removing it.
User's Guide
Replacing the Maintenance Cartridge
939
