Canon imagePROGRAF iPF6450 User Manual page 535

iPF6450
• Borderless printing on A1 or A2 rolls
Attach the included Spacer for Borderless Printing to the Roll
Holder.
Insert the protrusions (b) of the Spacer for Borderless Printing (a)
into the holes (c) of the Roll Holder, as shown.
3
With the Roll Holder resting horizontally and the edge of
the roll paper facing forward as shown, insert the roll in
the Roll Holder from the left. Insert the roll firmly until it
touches the flange (a) of the Roll Holder, leaving no
gap.
•
Always have the Roll Holder resting horizontally when loading rolls. Attempting to load rolls with the Roll Holder
upright may damage the Roll Holder.
Important
4
Insert the Holder Stopper from the left in the Roll Holder as
shown. Push it firmly in until the flange (a) of the Holder Stop-
per touches the roll.
Attach the appropriate Holder Stopper for the size of the paper
core.
User's Guide
Loading Rolls on the Roll Holder
535
