Cannot adjust printhead.

Messages regarding printheads

Messages regarding printheads
Cannot adjust printhead. ...................................................................................................................................... 654

Wrong printhead. .................................................................................................................................................. 654

Printhead error. ..................................................................................................................................................... 654

Cannot recognize print head. ................................................................................................................................ 654

Execute printhead cleaning. .................................................................................................................................. 655
Cannot adjust printhead.
Cannot adjust printhead.
Cause
The Printhead nozzles are clogged.
The Printhead cannot be aligned;
highly transparent film is loaded.
Wrong printhead. Wrong printhead.
An incompatible Printhead has been installed.
Printhead error.
Printhead error.
Cause
There is a problem with the Printhead.
Cannot recognize print head.
Cannot recognize print head.
No Printhead is installed.
654
Execute Head Posi. Adj. again, as follows.
1.
Press the OK button to clear the error.
2.
Print a test pattern to check the nozzles.
(See "Checking for Nozzle Clogging.")
3.
Clean the Printhead if the nozzles are clogged.
(See "Cleaning the Printhead.")
4.
Execute Head Posi. Adj. again.
(See "Automatic Adjustment to Straighten Lines and Colors.")
Press the OK button to clear the error.
We recommend using a type of paper that you often use, other than film, for Printhead adjustment.
(See "Automatic Adjustment to Straighten Lines and Colors.")
Cause
Open the Top Cover and replace the Printhead with a new one.
(See "Replacing the Printhead.")
Follow these steps to replace the Printhead.
1.
Open the Top Cover.
2.
Replace it with a new Printhead.
(See "Replacing the Printhead.")
Follow these steps to replace the Printhead.
1.
Turn off the printer, wait a while, and then turn it on again.
2.
Open the Top Cover.
3.
Replace it with a new Printhead.
(See "Replacing the Printhead.")
Cause
Corrective Action
P.576
➔
P.577
➔
Corrective Action
P.578
➔
Corrective Action
P.578
➔
P.578
➔
Corrective Action
Follow these steps to install the Printhead.
1.
Open the Top Cover.
2.
Install the Printhead.
(See "Replacing the Printhead.")
iPF6400SE
P.552
➔
P.552
➔
P.578
➔
User's Guide
