Fourier MultiLogPRO User Manual page 78

Press the Backward
Press Escape
Press Escape
Time and Speed
In this mode MultiLogPRO measures time and speed either in one gate or
between gates
_ _ _ _ _ T I M I N G _ _ _ _ _
 M o d e : T i m e S p e e d
Press Enter to select this mode. The arrow moves to the Measure row
Use the Forward
to measure time and speed in one gate or In1  In2 if you want to measure
time and speed between two gates
Time and speed at one gate
MultiLogPRO measures the time
between blocking and unblocking the
photogate at input 1
1. Press Enter
arrow buttons to select the card
72 MultiLogPRO
arrow to reset the watch
to exit the stopwatch mode and return to the timing menu
a second to return to the main menu
M e a s u r e : I n 1
C a r d w i d t h : 3 0 m m
G a t e s d i s t a n c e :
S t a r t ( > )
and Backward
, then use the
_ _ _
arrow buttons to select In1 if you want
Time and speed between gates
MultiLogPRO measures the time
between blocking the photogate at
input 1and blocking the photogate at
input 2
1. Press Enter twice, then use
