4 Station Installation

4.1 Installation Options

4.1.1 Standard Cable Connection

The MultiLogPRO is directly connected to the computer by 30m serial
cable.
If you are using this option skip steps 4.2.12, 4.2.14.A and 4.2.16.A of
the installation.
You won't need items 3.3, 3.9.4, 3.9.6 and 3.13 to 3.16 from the part list.

4.1.2 Wireless Connection

The MultiLogPRO is connected to an RF transmitter and the data is
transmitted to a receiver that is connected to the computer.
If you are using this option skip steps 4.2.14.B and 4.2.16.B of the
installation.
You won't need item 3.11 from the part list.
The transmission range is 300m if the transmitter and the receiver are in
line of sight. If not the range is reduced considerably and depends on the
medium between the transmitter and the receiver
Note: In wireless mode, transmission is one way only, from MultiLogPRO to the
computer. There is no way of programming or operating the
MultiLogPRO via the software, therefore there are two steps to take if
you wish to reprogram your Weather Station. Firstly, temporarily connect
MultiLogPRO to the computer with the supplied communication cable
(step 4.2.15) and set it up. Secondly, set the system to transmit data by
pushing the Enter button on the MultiLogPRO itself.
