4. Menu Icons and commands
Start
Press the Enter button to start recording
Setup
Rate – select recording rate
Samples – select the total number of recording points
Display – select the way MultiLogPRO will display the data
(at a rate of up to 10 samples per second):
1) Numeric
2) Meter
3) Table
4) Graphic
At rates higher then 10/s the MultiLogPRO will display the
data in a graph at the end of the logging period.
Start – Press the Forward arrow to start recording
Function
1) Minimum – The minimum graph value.
2) Maximum – The maximum graph value.
3) Average – The graph average.
Start recording
Setup MultiLogPRO in 4 steps:
Displays the sensor values and the
sample number.
Displays all active sensors in a bar
meter display along with their values.
Displays the last 6 values of all the
active sensors in a table.
Displays a graphic representation of the
sampled sensors.
Display statistics of the current data
