A. Click Offline on the menu bar, point to Time span and then select
the desired time span.
B. WeatherLab will display data from the selected time span starting
from the date that is currently displayed at the left side of the
graph.
C. Click Next 24 hours
click Previous 24 hours
backward.
3. Rain bars
Click Display rain bars

5.4.6 Four Graph Display

If you want to view a large number of data series simultaneously you may find it
convenient to use the four graph display.
Click Four graph display
display
The data series are grouped in four separate graphs with identical time axis.
To change the data that is being displayed in any graph:
Right click on the right or left y-axis end select an axis title from the popup list
The cursor, the zoom tool and the panning tool are active and operate the same
as in the one graph display.

5.4.7 Table

Click on the Table button

5.4.8 The Cursor

Use the cursor to view individual data recording values, or to reveal a hidden Y-
axis.
42 WeatherLab
to scroll the display one day forward or
to scroll the display one day
to display the rainfall in daily rain bars
on the lower toolbar to switch to one graph
to display the data in table.
