Configuration

6.2.5 Graphic Display

MultiLogPRO will automatically use a graphic display in three cases:
1. If the recording rate is 10/s or less and you selected Graphic
Display in the setup menu
2. Once logging has ended for an experiment with a data recording
rate of over 10/s
3. When opening a stored recording.
The graphic display is available for recordings with up to 4 sensors
simultaneously.
Configure the MultiLogPRO:
Input Mode – Select Input Mode: Auto ID or 8 inputs
Memory clear – Delete the stored data files
Distance – Select the range of the Distance sensor: 1.5m or
10m
DO2 – Press the Forward arrow button to enter the DO
menu
Contrast – Use the arrow buttons to tune the screen
contrast
Comm – Press the Forward arrow button to connect to a
computer or the Backward arrow button to connect to TI
calculator
2
MultiLogPRO 69
