10 • Getting Started with the SmartNode Device
1. Configure IP address
Power connection and default configuration
First the SmartNode must be connected to the mains power supply with the power cable. Wait until the Run
LED stops blinking and lights constantly. Now the SmartNode is ready.
The factory default configuration for the Ethernet interface IP addresses and network masks are listed in
Table 42. Factory default IP address and network mask configuration
Interface Ethernet 0 (ETH0)
Interface Ethernet 1 (ETH1)
Both Ethernet interfaces are activated upon power-up.
If these addresses match with those of your network, go to section
on page 144. Otherwise, refer to the following sections to change the addresses and network masks.

Connect with the serial interface

The Console port is wired as an EIA-561, RS-232 port. Use the included Model 16F-561 adapter and cable (see
figure 88) between the SmartNode's Console port and a PC or workstation's RS-232 serial interface. Activate the
terminal emulation program on the PC or workstation that supports the serial interface (e.g. HyperTerm).
142
IP Address
172.16.40.1
192.168.1.1
The Interconnecting cables shall be acceptable for external use and shall be
rated for the proper application with respect to voltage, current, anticipated
temperature, flammability, and mechanical serviceability
SmartNode 1000 and 2000 Series Getting Started Guide
"2. Connect the SmartNode to the network"
table
Network Mask
255.255.0.0
255.255.255.0

1. Configure IP address

42.
