SmartNode 4740 Series (16–32 Ports) User Manual
ping 192.168.1.1
or
smartnode.local

Configure the Desired IP Address

Factory-default IP Settings

The factory default configuration for the Ethernet interface IP addresses and network masks are listed in Table 6.
Both Ethernet interfaces are activated upon power-up. LAN interface ETH 0/1 (LAN) provides a default
DHCP server, the WAN interface uses DHCP client to automatically assign the IP address and network mask.
Table 6. Factory Default IP Address and Network Mask Configuration
WAN Interface Ethernet 0 (ETH 0/0)
LAN Interface Ethernet 1 (ETH 0/1)
DHCP Address Range
If these addresses match with those of your network, go to section
work" on page 36. Otherwise, refer to the following sections to change the addresses and network masks.

Login

To access the SmartNode, start the Telnet application. Type either the host name
smartnode.local
or the default IP address into the address field of the Telnet application:
192.168.1.1
Accessing your SmartNode via a Telnet session displays the login screen. Type the factory default login: admin
and leave the password empty. Press the Enter key after the password prompt.
login:admin
password: <Enter>
192.168.1.1>
After you have successfully logged in you are in the operator execution mode, indicated by > as command line
prompt. With the commands enable and configure you enter the configuration mode.
192.168.1.1>enable
192.168.1.1#configure
192.168.1.1(cfg)#
You are responsible for creating a new administrator account to maintain system secu-
rity. Patton Electronics accepts no responsibility for losses or damage caused by loss or
misuse of passwords. Refer to Chapter 4 "Accessing the CLI" , section "Selecting a secure
IMPORTANT
password" in the

Configure the Desired IP Address

DHCP
192.168.1.1
192.168.1.10–192.168.1.99
Trinity Command Line Reference Guide
IP Address
DHCP
255.255.255.0
255.255.255.0
"Connecting the SmartNode to the Net-
for more details.
4 • Initial Configuration
Network Mask
35
