User Manual
SmartNode™ 10100 Series
TDM+VoIP Smart Media Gateway
Quick Start Guide
This is a Class A device and is not intended for use in a residential environment.
Part Number: 07MSN10100-QS, Rev. A
Revised: April 9, 2014
Sales Office: +1 (301) 975-1000
Technical Support: +1 (301) 975-1007
E-mail: support@patton.com
WWW: www.patton.com
Advertisement
Table of Contents
Related Manuals for Patton SmartNode 10100 Series
Summary of Contents for Patton SmartNode 10100 Series
-
Page 1: Quick Start Guide
Quick Start Guide This is a Class A device and is not intended for use in a residential environment. Sales Office: +1 (301) 975-1000 Part Number: 07MSN10100-QS, Rev. A Technical Support: +1 (301) 975-1007 E-mail: support@patton.com Revised: April 9, 2014 WWW: www.patton.com... - Page 2 In accordance with the requirements of council directive 2002/96/EC on Waste of Electrical and Electronic Equipment (WEEE), ensure that at end-of-life you separate this product from other waste and scrap and deliver to the WEEE collection system in your country for recycling. SmartNode 10100 Series Quick Start Guide...
-
Page 3: Before You Begin
• One warranty sheet • One packing slip • One SmartNode 10100 Series Quick Start Guide • One SmartNode 10100 Important Notice sheet with unique information for your specific unit • To install the SN10100, you will need (not included): Two AC power cords •... -
Page 4: Connecting To The Voip Network
If your system employs a second Gigabit Ethernet switch for redundancy, connect a second CAT5 Ethernet cable to VoIP1and the other end to the second Gigabit Ethernet switch. Figure 2. Connecting the VoIP ports SmartNode 10100 Series Quick Start Guide... -
Page 5: Connecting To The Pstn Network
The SN10100 connects to two independent power sources. If only one power source is used, press the green but- ton at the rear of the unit to disable the audible alarm. Connect an AC power cable between the AC connector of the SN10100 and an AC supply. SmartNode 10100 Series Quick Start Guide... - Page 6 Connect the other lead of the DC power cable to the negative side of the DC power source. Repeat steps 1-3 for the second DC power source, if necessary. Figure 5. DC Power Connection(s) SmartNode 10100 Series Quick Start Guide...
-
Page 7: Connecting The Ethernet Management Interface
SN10100. If your computer’s serial port features a USB connector, you will need to provide a USB to DB9 adapter. Figure 6. Computer to the Console Serial port 6.2 Connecting the Ethernet management interface Connect the supplied CAT5 Ethernet cable to the management port labeled Ethernet on the front of the SN10100. SmartNode 10100 Series Quick Start Guide... - Page 8 Login to the console using the specific credentials included on the “Important Notice” sheet that shipped with your unit. (If you do not have the “Important Notice” sheet, contact support@patton.com.) The fac- tory default configuration for the Ethernet Interface IP address is 192.168.200.10/24.
-
Page 9: Logging Into The Web Interface
For debugging assistance, contact Patton’s Support team at support@patton.com. Once your IP Address and Time Zone are set, there are no more configuration steps in the CLI and you may proceed to the web manage- ment page. -
Page 10: Additional Information
Default password: root – 9.0 Additional Information Refer to the following manuals—available online at www.patton.com/manuals—for detailed information about installing, configuring and operating the SN10100 models, along with warranty, trademark and compli- ance information. SmartNode 10100 Series User Manual —www.patton.com/manuals/SN10100.pdf •... -
Page 11: Ce Declaration Of Conformity
A.3 CE Declaration of Conformity Patton Electronics, Inc declares that this device is in compliance with the essential requirements and other rele- vant provisions of Directive 1999/5/EC. The Declaration of Conformity may be obtained from Patton Electron- ics, Inc at www.patton.com/certifications. - Page 12 Trademarks statement The term SmartNode is a trademark of Patton Electronics Company. All other trademarks presented in this docu- ment are the property of their respective owners. Warranty, Trademark, & Compliance Information For warranty, trademark and compliance information, refer to the user manual for your SN10100 model, avail- able online at www.patton.com/manuals.
