01.93
228*
Alarm No.
Alarm Text:
"Option M19 missing"
Alarm No.
M19 S... was programmed in the part program although this function is
not implemented in the control.
Alarm Text:
• Check program
• Check NC MD
• Upgrade with option E42
3000
Alarm No.
Alarm Text:
"General program error"
Reason:
– In one block of the program, a general, not precisely definable,
programming error was made.
Example:
– "Axis duplication" option is active and D number in the part program
> 49.
Remedy:
– Check the faulty block in "Correction block".
If possible, the cursor is positioned in front of the word containing
the error. The number of the block containing the error is displayed
in the alarm line after the alarm No.
– Change part program
3001
Alarm No.
Alarm Text:
"Geometry parameters > 5"
Reason:
More than 5 geometry parameters, such as axes, interpolation
parameters, radii, angles have been programmed in a block.
Remedy:
As for alarm 3000
3002
Alarm No.
Alarm Text:
"Polar / radius error"
Reason:
In a block with polar/radius programming:
– no angle
– no radius
– no coordinates for the centre point have been programmed
Remedy:
As for alarm 3000
3003
Alarm No.
Alarm Text:
"Invalid address"
Reason:
– Axis duplication active and axes of tool system 2 programmed in the
part program.
– An address has been programmed that is not defined in machine
data.
Effect:
NC START inhibited.
Remedy:
Change part program.
© Siemens AG 1990 All Rights Reserved
SINUMERIK 810T, GA3 (BN)
– An axis was programmed that is not present on the
machine
– An incorrect interpolation parameter was programmed
6ZB5 410-0EP02
4 Monitoring Functions
4.6 Listing of the alarms/alarm description
4-25
