Setting up the QSX
™
System
What's in the box?
QSX 400
QSX 300
(for SoundStation
VTX 1000™)
QSX System
Documentation Library
1
Decide where to place the QSX system
Make sure that the location you choose allows all of the cables
to connect easily to the QSX base. The following diagram shows
a typical installation.
Cables for the computer and phone
connect to the QSX base through
a cable port in the table.
The QSX base connects to
power and networking at the table.
QSX
IOIOIO
LAN
Cables from the display and phone
wall/floor module connect easily
from their installed locations.
2
Mount the system with brackets (optional)
Other mounting options
3
Connect power, a display, and the network
IOIOIO
The QSX default network setting is DHCP . For more information,
see the Administrator's Guide.
4
Connect a conference phone
Connect a SoundStation VTX 1000 conference phone
IOIOIO
You may need to upgrade your SoundStation VTX 1000 software.
For version information, see the Release Notes available at
www.polycom.com/resource_center.
LAN
LAN
LAN
Advertisement
Related Manuals for Polycom QSX 400
Summary of Contents for Polycom QSX 400
- Page 1 IOIOIO Cables for the computer and phone connect to the QSX base through a cable port in the table. The QSX base connects to QSX 400 QSX 300 (for SoundStation power and networking at the table. VTX 1000™) IOIOIO The QSX default network setting is DHCP .
