The QSX ™ System Quick Start Guide

Unit Overview

8-wire conference
phone connector
Connect to conference
phone (if phone is
used.)
Power connector
Connect to power
supply
Included in the Box
Cable Bag
* LAN Cable
* Power Cord
* Power Supply
* 8-Wire Cable for phone console
* Mounting Brackets
For information about configuring the QSX system, see the QSX Administration Guide.
For the latest product information, see the Release Notes available at www.polycom.com/resource_center.
For product support, visit the Polycom Support Center at www.polycom.com/support.
Conference link
connector
Connect to SoundStation
VTX 1000 only (if phone is
used.)
POTS module
VGA output
connector
Connect to VGA
Connect to conference
monitor or
phone interface
projector
module (if phone is
used)
RS-232 connector
Audio connectors
Use to reset forgotten
Reserved for future
password or set a static
use (inactive)
IP address (optional)
IOIOIO
VGA input
Connect to
content controller
or computer
QSX 400
* Content Controller with VGA Cable
* 3 foot VGA Extension
* Straight-through Serial Cable
QSX 300
(
for use with SoundStation VTX 1000
* VGA Cable
* Straight-through Serial Cable
* Conference Link Cable
LAN
LAN connector
Connect to LAN
)
