Microphones and Speakers

Connecting Audio Input

Connecting Audio Input to Polycom QDX 6000 Systems

Audio Input Number
Mic 1
Mic 2
Line In (Main Audio)
VCR IN (VCR/DVD
Player)

Connecting Devices to the Polycom QDX 6000 Microphone Input

Make sure that the system is powered off before you connect devices to it.
The following table shows the acceptable input levels and video associations
for the audio inputs on a Polycom QDX 6000 system.
Connector Acceptable Input Source Levels
RJ-9 Polycom microphone
RJ-9 Polycom microphone
RCA Line Level
RCA Mono/Stereo Line Level
To pick up audio from your site, you must connect a microphone to the
Polycom QDX 6000 system. Refer to your system's setup sheet for connection
details.
The microphone picks up sound from the sides. You can connect two Polycom
microphones to a Polycom QDX 6000 system.
Video Association
None
None
None
Can be associated to any video
source, or without association to
a video source. For more
information about this setting,
refer to Auxiliary Audio Input
Association on page 4-5.
4
4 - 1
