Modifying TI zones

Example
The following example creates TI zones in the base fabric shown in

Modifying TI zones

Using the zone
option, or both.You can also activate or deactivate the TI zone.
Using the zone
the last member of a TI zone, the TI zone is deleted.
After you modify the TI zone, you must enable the current effective configuration to enforce the
changes.
ATTENTION
If failover is disabled, do not allocate all ISLs in TI zones. Make sure sufficient non-dedicated paths
exist through the fabric for all devices that are not in a TI zone. See
for additional information about disabling failover mode.
NOTE
If you have overlapping TI zones and you want to change the failover option on these zones, you must
first remove the overlapping ports from the zones, then change the failover type, and finally re-add
the overlapping members.
1. Connect to the switch and log in using an account with admin permissions.
2. Enter one of the following commands, depending on how you want to modify the TI zone.
3. Perform the following steps if you have any TI zones with failover disabled. If all of your TI zones
288
BS_D1> zonecreate "z1", "1,1"
BS_D1> cfgcreate "base_cfg", z1
BS_D1> zone --create -t ti -o f "ti_zone2" -p "1,3; 1,10; 7,12; 7,14; 2,16;
2,8"
BS_D1> cfgenable "base_config"
add command, you can add ports to an existing TI zone, change the failover
--
remove command, you can remove ports from existing TI zones. If you remove
--
•
Enter the zone add command to add ports or change the failover option for an existing
--
TI zone. You can also activate or deactivate the zone.
zone --add [-o optlist] name -p "portlist"
zone --add -o optlist name [-p "portlist"]
•
Enter the zone remove command to remove ports from an existing TI zone.
--
zone --remove name -p "portlist"
Be aware of the ramifications if you disable failover mode. See
for information about disabling failover mode.
are failover-enabled, skip to
a. Change the failover option to failover enabled. This is a temporary change to avoid frame
loss during the transition.
zone --add -o f name
b. Enable the zones.
cfgenable "current_effective_configuration"
step 4.
Figure 44 on page 283:
"TI zone failover" on page 270
"TI zone failover" on page 270
