VLAN Configuration

To display the following form, go to the VLANs Configuration form. Select a VLAN ID, or open the Virtual
LANs folder and click Add VLAN.
The commands on this form configure VLAN attributes, change the status of the VLAN, delete the VLAN,
and change the port membership of the VLAN.
By default, the VLAN menu option is disabled except VLAN 1, which is enabled all the time. The
HP 10GbE switch supports a maximum of 1,000 VLANs. VLAN 4095 is reserved for switch management.
The following table describes the VLAN Configuration controls:
VLAN Configuration controls
Table 117
Control
VLAN Name
VLAN ID (1-4094)
VLAN State
Spanning Tree Group
Description
Assigns a name to the VLAN or changes the existing name. The default VLAN name is
the first one.
Assigns a numeric identifier to the VLAN.
Enables or disables the VLAN.
Assigns a VLAN to a Spanning Tree Group. The range is 1-127. If MSTP is used, the
range is 0-32 (0 = CIST).
Configuring the switch
179
