Table 15
Forwarding Database Information controls
Control
VLAN
Source Port
Trunk
State
Learned Port
Permanent
An address that is in the forwarding (FORWARD) state means that the switch has learned it. When in the
trunking (TRUNK) state, the port field represents the trunk group number. If the state for the port is listed as
unknown (UNKNOWN), the MAC address has not yet been learned by the switch, but has only been seen
as a destination address. When an address is in the unknown state, no outbound port is indicated.
VLANs Dashboard
To display the following form, select Layer 2 > Virtual LANs (click the underlined text, not the folder).
This form displays information for all configured VLANs and all member ports that have an active link
state.
Description
Displays the VLAN number of the FDB entry.
Displays the source port of the FDB entry.
Displays the trunk number of the FDB entry, if applicable.
Displays the port state of the FDB entry.
Displays the port number of the port that received the FDB entry.
Displays whether the FDB entry is a static, permanent entry.
Dashboard
36
