Table 178
Access Control List Configuration controls
Control
Statistics
Egress Port

ACL Metering Configuration

To display the following form, go to the ACL Configuration Table form, and select an ACL number, or
open the Access Control Lists folder and click Add ACL.
The following table describes the ACL Metering Configuration controls:
ACL Metering Configuration controls
Table 179
Control
Committed rate
(1000 - 1000000 kb/s)
Maximum burst Size
(32 - -4096 kb/s)
Set out of profile to Drop or
Pass
Enable
Description
Enables or disables the statistics collection for the ACL.
Selects an egress port to add to the ACL.
The egress port ACL will not match a Layer 2 broadcast or multicast packet. The
egress port ACL will not match packets if the destination port is a trunk.
Description
Configures the committed rate, in Kilobits per second. The committed rate must be a
multiple of 1,000.
Configures the maximum burst size, in Kilobits. Enter one of the following values for
mbsize: 32, 64, 128, 256, 512, 1024, 2048, 4096
Configures the ACL Meter to either drop or pass out-of-profile traffic.
Enables or disables the ACL meter.
Configuring the switch
255
