firmware
displaying current version 61
downloading 81
specifying path and filename 81
updating 50, 81
flash memory, saving changes to 56
flow control
configuring for switch ports 36, 59
description 14
setting for optional module 60
fragments 108
frames
broadcast 110
multicast 110
tagged 15
unicast 110
viewing for individual ports 107
G - J
GARP 21
gateway, default 58
general information
viewing using Local Management 61
viewing using Web Device Manager 49
GVRP 93
configuring 44, 103
description 21
status 104, 114
Head of Line (HOL) blocking prevention 62
High Priority Service Ratio 62
hot keys, using 55
HyperTerminal, default parameters 53
IEEE 802.1p priority tags, description 15
IEEE 802.1Q VLAN. See tag-based VLAN
IGMP, description 22, 67
IGMP snooping
configuring 67
on VLAN 67, 94, 95
status 111
in-band connection through Telnet 54
ingress filter 103
ingress filtering 44
