Media Requirements

Incorrect cabling is often the cause of network performance problems. Read
the next two pages to make sure your cabling is correct.
100Base-TX
The 100Base-TX Fast Ethernet specification requires that you use CAT 5
UTP cabling to operate at 100Mbps. If you use lower grade cabling (CAT 3
or CAT 4), you may get a connection, but also experience data loss or slow
performance. You're limited to 100 meters between any two devices.
10Base-T
The 10Base-T Ethernet specification allows you to use CAT 3, CAT 4, or
CAT 5 UTP cabling. The limit is 100 meters between any two devices.
100Base-FX
The optional Fiber Module lets you connect to a switch up to 400 meters
(hubs up to 160m) away at half-duplex or up to 2 km at full-duplex. Use
62.5/125 m multimode fiber optic cable with an SC-type fiber optic
connector.
1000Base-T
The 1000Base-T Gigabit specification requires that you use CAT 5 UTP
cabling to operate at 1000Mbps. If you use a lower grade cabling you will
experience either no connection or extreme data loss. The maximum
distance between any two devices is 100 meters.
1000Base-SX/1000Base-LX
The optional 1000Base-SX and -LX Gigabit Modules provide a high-speed
connection to another device up to 5 km away. The maximum distance
depends on the type of cable used. Refer to the following table for a list of
cable types and maximum distances. Use cables with an SC-type fiber optic
connector.
