Intel CELERON PROCESSOR P4505 - DATASHEET ADDENDUM Datasheet page 65

Processor Ball and Signal Information
Table 13.
Pin #
N38 PEG_TX[1]
N40 PEG_TX#[0]
N42 VCC
N44 VCC
N46 VSS
N48 VCC
N50 VSS
N51 VCC
N53 VSS
N55 VCC
N57 VSS
N61 CATERR#
N63 VSS
N65 TMS
N67 PROCHOT#
N70 RESET_OBS#
P1 FDI_TX#[3]
P4 VSS
P34 PEG_RX#[3]
P60 VCC
P69 TRST#
P71 TDI_M
R2 FDI_TX[3]
R5 VSS
R7 FDI_TX#[5]
R8 FDI_TX[5]
R12 VSS_SENSE_VTT
R14 VSS
R15 VTT1
R17 VTT1
R19 VTT1
R21 VTT1
R23 VTT0
R24 VTT0
R26 VTT0
® TM
Intel Core i7-660UE, i7-620LE/UE, i7-610E, i5-520E, i3-330E and Intel
August 2010
Document Number: 323178-003
® TM
Intel Core i7-660UE,
i7-620LE/UE, i7-610E,
i5-520E, i3-330E and
® ®
Intel Celeron
Processor P4505,
U3405 Series Ball List
by Ball Number
Buffer
Pin Name
Type
PCIe
PCIe
REF
REF
GND
REF
GND
REF
GND
REF
GND
GTL
GND
CMOS
Async GTL
Async CMOS
FDI
GND
PCIe
REF
CMOS
CMOS
FDI
GND
FDI
FDI
Analog
GND
REF
REF
REF
REF
REF
REF
REF
Dir
O
O
I/O
I
I/O
O
O
I
I
I
O
O
O
O
® ®
Celeron Processor P4505, U3405 Series
Datasheet Addendum
65
