Contents
1 Introduction and Features Summary ......................................................................... 8
1.1 Introduction ....................................................................................................... 8
1.2 Interfaces ........................................................................................................ 10
1.2.1 System Memory Support ......................................................................... 10
1.2.2 PCI Express* ......................................................................................... 10
1.3 Package ........................................................................................................... 11
1.4 Terminology ..................................................................................................... 12
1.5 Related Documents ........................................................................................... 13
2 Interfaces................................................................................................................ 15
2.1 System Memory Interface .................................................................................. 15
2.1.1 System Memory Technology Supported ..................................................... 15
2.1.2 System Memory Timing Support............................................................... 16
2.1.3 System Memory Organization Modes......................................................... 16
2.1.4 Rules for Populating Memory Slots ............................................................ 18
2.1.5 Technology Enhancements of Intel
2.1.6 DRAM Clock Generation........................................................................... 19
2.1.7 DDR3 On-Die Termination ....................................................................... 19
2.2 PCI Express* Interface....................................................................................... 19
2.2.1 PCI Express* Configuration Mechanism ..................................................... 19
2.2.2 PCI Express Port Bifurcation..................................................................... 20
3 Signal Description ................................................................................................... 21
3.1 System Memory Interface .................................................................................. 21
3.2 Reset and Miscellaneous Signals.......................................................................... 24
4 Electrical Specifications ........................................................................................... 25
4.1 Signal Groups ................................................................................................... 25
4.2 DC Specifications .............................................................................................. 25
4.2.1 Voltage and Current Specifications............................................................ 25
5 Processor Ball and Signal Information ..................................................................... 27
5.1 Processor Ball Assignments................................................................................. 27
6 Processor Configuration Registers ........................................................................... 70
6.1 Register Terminology ......................................................................................... 70
6.1.1 DEVEN - Device Enable ........................................................................... 72
6.1.2 ERRSTS - Error Status ............................................................................ 73
6.1.3 ERRCMD - Error Command ...................................................................... 74
6.1.4 SMICMD - SMI Command ........................................................................ 76
6.1.5 C0WRDATACTRL - Channel 0 Write Data Control......................................... 77
6.1.6 COECCERRLOG - Channel 0 ECC Error Log ................................................. 78
6.1.7 C1WRDATACTRL - Channel 1 Write Data Control......................................... 80
6.1.8 C1ECCERRLOG - Channel 1 ECC Error Log ................................................. 80
6.2 PCI Device 6..................................................................................................... 81
6.2.1 VID6 - Vendor Identification .................................................................... 85
6.2.2 DID6 - Device Identification..................................................................... 85
6.2.3 PCICMD6 - PCI Command........................................................................ 86
6.2.4 PCISTS6 - PCI Status.............................................................................. 88
6.2.5 RID6 - Revision Identification................................................................... 90
6.2.6 CC6 - Class Code ................................................................................... 90
6.2.7 CL6 - Cache Line Size ............................................................................. 91
6.2.8 HDR6 - Header Type ............................................................................... 91
6.2.9 PBUSN6 - Primary Bus Number ................................................................ 92
® TM
Intel Core i7-660UE, i7-620LE/UE, i7-610E, i5-520E, i3-330E and Intel
August 2010
Document Number: 323178-003
®
Fast Memory Access (Intel
® ®
Celeron Processor P4505, U3405 Series
®
FMA).......... 18
Datasheet Addendum
3
