A
RAID Module
B
Battery Backup Unit
C
Power Supply
D
Backplane
E
Optical Drive
F
Fan Modules
G
Power from BBU
to RAID Module
H
F
P
O
®
Intel
Server System SR1690WB Service Guide
A
Server Board
L
L
K
1
2
3
N
HDD 0
HDD 1
G
5
0
4
1
3
2
I
J
4
Q
M
D
HDD 2
E
H
SES cable from RAID
Module to Backplane
I
Main Power
J
Aux. Signal Power
K
CPU Power
L
Power to Fans
M
Power to Optical Drive
N
Power to Backplane(2)
O
IPMB Cable from Backplane
P
SGPIO Cable from Backplane
Q
SATA Data Cables
C
B
N
HDD 3
AF003307
7
