Configuration Jumpers
BMC Force Update
J1B5
Normal
Update
Password Clear
J1C2
Normal
Clear
Password
BIOS Recovery Mode
J1C3
Normal
Recovery
5HVHW %,26 &RQÀJXUDWLRQ
J1B4
Normal
Reset BIOS
&RQÀJXUDWLRQ
®
Intel
Server System SR1690WB Service Guide
6HULDO ,QWHUIDFH
9LGHR 0DVWHU
J6A3
DCD to DTR
Internal
External
DSR to DTR
J6A2
ME BMC Update
J7A2
AF003049
