Rear of Server System
A
A.
AC Power Receptacle
B.
NIC 1 connector
C.
Top Cover Release Screw
D.
PCI Express* Add-in Card
E.
IO module external connector 2 (optional)
F.
IO module external connector 1 (optional)
G.
Management Network Interface (optional)
H.
Internal Video Connector
Peripheral Devices
The server system provides locations and hardware for installing hard drives and a
slimline optical drive. You must purchase the drives separately. The following figure
shows the available options.
A
E
D
®
Intel
Server System SR1690WB Service Guide
B
N
L
J
M
K
I
Figure 9. Server System I/O Connector Locations
C
C
H
G
F
I.
RJ-45 Serial B port
J.
NIC2 Connector
K.
USB port 9
L.
USB port 8
M. USB port 5
N.
USB port 2
B
D
E
AF003220
AF003221
19
