2
Server System Features
This chapter briefly describes the main features of the Intel
This chapter provides illustrations of the product, a list of the server system features, and
diagrams showing the location of important components and connections on the server
system.
Table 2
Dimensions
Raw Storage Capacity
External Drive Bays
Hard Disk Drive
Supported
Figure 1. Intel
summarizes the features of the server system.
®
Table 2. Intel
Server System SR1690WB Feature Summary
Feature
•
1.69 inches (43mm) high
•
17.76 inches (451.17mm) wide
•
26.42 inches (671.08mm) deep
•
24.58 lbs (11.15kg) weight
System raw storage capacity is based on the HDD capacity and
number of HDDs used in the system. Raw storage capacity is the sum
of single HDD capacity used in system.
Four hot-pluggable external drive bays
•
3.5-inch SATA, SAS HDD.
•
2.5-inch SATA, SAS HDD.
®
Server System SR1690WB
Description
®
Server System SR1690WB.
AF003210
3
