12
Jumper Name
Pins
J8C1: BMC
1-2
Force Update
2-3
Password
1-2
Clear(J1C2)
2-3
BIOS
1-2
Recovery(J1C3)
2-3
Reset BIOS
1-2
Configuration(J1
2-3
B4)
Video
1-2
Master(J6A3)e
2-3
Serial
1-2
Interface(J6A2)
2-3
None

Figure 5. Configuration Jumper Location

What happens at system reset...
BMC Firmware Force Update Mode -
Disabled (Default)
BMC Firmware Force Update Mode -
Enabled
Normal System Operation (Default)
Administrator and user passwords are
cleared on the next reset
Normal System Operation (Default)
The main system BIOS will not boot with
these pins jumpered. Note: the system boots
from EFI-bootable recovery media with a
recovery BIOS image.
Normal System Operation (Default)
Clear CMOS settings
Internal connector overrides
External connector overrides
DTR (Data Terminal Ready) mode
DCD (Data Carrier Detect) mode
DSR (Data Set Ready) mode
®
Intel
Server System SR1690WB Service Guide
