Note: Do not touch the socket pins; they are very sensitive and easily damaged.
9. Align the processor cutouts to match the two socket pins, and then insert the
processor into the socket as shown in
10. Close the load plate (see the letter "A" in
ensure the load plate tab engages under the socket lever when fully closed. (See
letter "B" and "C" in
Note: Make sure the alignment triangle mark and the alignment triangle cutout align correctly.
To assist in package orientation and alignment with the socket:
®
Intel Server System SR1690WB Service Guide
A

Figure 21. Aligning the Processor

Figure 22)
A

Figure 22. Close the Load Plate and Socket Lever

Figure 21.
Figure 22), close the socket lever and
C
B
B
AF003293
AF003294
33
