Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Table 9
Counter
sys_rx_unopen_vc_cls
sys_ecc_errors
These counters are only cleared when the line card is reloaded.
Note
Obtaining Per-VC Counters
To display per-VC counters, first you must determine what connection ID is associated with the VC. This
procedure differs slightly, depending on the version of Cisco IOS you are running. The following
procedure describes how to display the per-VC counters in Cisco IOS release 12.0(27)S or later.
Retrieve the VCD by using the show atm pvc command on the RP.
Step 1
router# show atm pvc
Interface
0/0.1
In this example, the VCD for the VC whose VCI/VPI are 1/100 is 2.
Use the show controller atm command to get the connection ID for VCD 2:
Step 2
router# exec slot 0 show controller atm 0 traffic
========= Line Card (Slot 0) =========
VCID CONNID InPkts
2
For the example above, the
Now specify the connID in the show controller atm traffic command and view the VC statistics:
Step 3
Router# exec slot 0 show controller atm 0 traffic 1
========= Line Card (Slot 1) =======
VCID: 2, CONNID: 1, VPI: 1, VCI: 100
Rx Total Stats:
rx_packets : 0 rx_bytes : 0
rx_resource_err: 0 rx_other_err : 0
rx_sw_packets : 0 rx_oam_cells : 0
Tx Stats:
COSQ #0 (ChID=010D)
tx_packets :
tx_resource_err: 0
tx_queue_depth : 0
tx_random_drop : 0
COSQ #1 (ChID=010E)
show controller atm Counters (continued)
Description
Packets received on nonexistent VC.
Total number of single bit errors detected on the
reassembly SAR.
VCD/
Name VPI VCI TYPE Encaps
2 1 100 PVC
InBytes PktsInSW
1 0 0
connID for VC 1/100 is 1.
0 tx_bytes :
tx_other_err :
tx_avg_q_depth:
tx_thresh_drop:
Troubleshooting ATM Errors on the 4-Port ATM ISE Line Card
Peak Avg/Min
Kbps Kbps
SNAP 23000 N/A
InOams OutPkts
0 0 0
0.0000
Comments
Also available in the
show atm traffic
command on the RP.
Burst
Cells Sts
UP
OutBytes
0
0
0
0
Cisco IOS Release 12.0(27)S
