Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Command or Action
Step 9
pvc vpi/vci l2transport
Example:
Router(config-if)# pvc 1/200 l2transport
Step 10
service-policy input policy-map-name
Example:
Router(config-atm-l2trans-pvc)# service-policy
input atm-policy
Step 11
xconnect peer-router-id vcid encapsulation mpls
Example:
Router(config-atm-l2trans-pvc)# xconnect
13.13.13.13 100 encapsulation mpls
Configuring Experimental Bits on a Port
This task describes how to configure the experimental bits in the MPLS header on a port.
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
DETAILED STEPS
Command or Action
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
enable
configure terminal
policy-map policy-map-name
class class-map-name
set mpls experimental mpls-exp-value
exit
exit
interface atmslot/port
service-policy input policy-map-name
xconnect peer-router-id vcid encapsulation mpls
How to Configure AToM VCs on the 4-Port ATM ISE Line Card
Purpose
Assigns a virtual path identifier (VPI) and virtual circuit
identifier (VCI). The l2transport keyword indicates that
the PVC is a switched PVC and not a terminated PVC.
Attaches a service policy to a VC and specifies the direction
in which the policy should be applied.
Binds the attachment circuit to a pseudowire VC or VP.
Purpose
Enables privileged EXEC mode.
Enter your password if prompted.
•
Enters global configuration mode.
Cisco IOS Release 12.0(27)S
