How to Configure Layer 3 Terminated VCs on the 4-Port ATM ISE Line Card

Command
Router# show atm interface atm slot/port
Router# show atm traffic
How to Configure Layer 3 Terminated VCs on the 4-Port ATM ISE
Line Card
The following configuration tasks are described in this section:
•
•
•
•
•
•
Configuring Layer 3 Terminated Virtual Circuits
A virtual circuit (VC) is a point-to-point connection between two ATM devices. A VC is established for
each ATM end node with which the router communicates. The characteristics of the VC are established
when it is created and include the following for the 4-Port ATM ISE line cards:
•
•
•
•
Permanent virtual circuits (PVCs) configured on the router remain active until the circuit is removed
from the configuration. All virtual circuit characteristics apply to PVCs. When a PVC is configured, all
configuration options are passed to the 4-Port ATM ISE line card. These PVCs are written to the
nonvolatile RAM (NVRAM) as part of the configuration and are used when the Cisco IOS image is
reloaded.
When you create a PVC, you create a virtual circuit descriptor (VCD) and attach it to the VPI and VCI.
The VCD tells the card which VPI/VCI to use for a particular packet. The 4-Port ATM ISE line card
requires this feature to manage the packets for transmission. The number chosen for the VCD is
independent of the VPI/VCI used.
A permanent virtual path (PVP) is like a bundle of VCs, transporting all cells with a common VPI, rather
than a specific VPI and VCI.
PVCs are created and configured using the pvc command in interface configuration mode. PVPs are
created and configured using the atm pvp command in interface configuration mode.
The syntax of the pvc command is as follows:
pvc [name] vpi/vci
Cisco IOS Release 12.0(27)S
8
Purpose
Displays current ATM-specification information about the 4-Port ATM ISE
line card interface.
Displays current ATM statistics.
Configuring Layer 3 Terminated Virtual Circuits, page 8
Configuring ATM Shaping on Terminated VCs, page 9
Configuring OAM Management on Terminated VCs, page 11
Configuring Quality of Service on Terminated VCs, page 14
Configuring and Managing VC Bundles, page 28
Configuring Bridged PVCs, page 35
Quality of service (QoS)
ATM adaptation layer (AAL) mode
Encapsulation type (LLC/SNAP, IP MUX, and NLPID)
Peak and average transmission rates
