How to Configure AToM VCs on the 4-Port ATM ISE Line Card
Command or Action
Step 5
queue-limit number-of-cells cells
Example:
Router(config-pmap-c)# queue-limit 300 cells
Step 6
exit
Example:
Router(config-pmap-c)# exit
Step 7
exit
Example:
Router(config-pmap)# exit
Step 8
interface atmslot/port
Example:
Router(config)# interface atm1/0
Step 9
atm clock internal
Example:
Router(config)# atm clock internal
Step 10
atm mcpt-timers [timer1-timeout timer2-timeout
timer3-timeout]
Example:
Router(config-if)# atm mcpt-timers 100 1000
5000
Step 11
pvc [name] vpi/vci l2transport
Example:
Router(config-if)# pvc 21/21 l2transport
Step 12
encapsulation aal0
Example:
Router(config-atm-l2trans-pvc)# encapsulation
aal0
Step 13
cell-packing cells mcpt-timer timer
Example:
Router(config-atm-l2trans-pvc)# cell-packing 10
mcpt-timer 1
Cisco IOS Release 12.0(27)S
56
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Purpose
Specifies or modifies the maximum number of cells the
queue can hold for a class policy configured in a policy
map.
Exits class mode.
Exits policy-map mode.
Specifies an ATM interface or subinterface to configure.
Causes the ATM interface to generate the transmit clock
internally.
Sets up the cell-packing timers, which specify how long the
PE router can wait for cells to be packed into an MPLS
packet.
You can set up to three timers. For each timer, you specify
the maximum cell packing timeout (MCPT). This value
gives the cell packing function a limited amount of time to
complete. If the timer expires before the maximum number
of cells are packed into an AToM packet, the packet is sent
anyway. The range of values is from 2 to 4095.
Specifies a PVC with the specified VPI and virtual circuit
identifier (VCI). The l2transport keyword indicates that
the PVC is a switched PVC and not a terminated PVC.
For ATM Cell Relay, this command specifies raw cell
encapsulation for the interface. Make sure you specify the
same encapsulation type on the PE and CE routers.
Enables cell packing and specifies the cell packing
parameters.
The cells value represents the maximum number of cells to
be packed into an MPLS packet. The range is from 2 to 28.
The timer value allows you to specify which timer to use.
