How to Configure AToM VCs on the 4-Port ATM ISE Line Card
Router(config-pmap)# exit
Router(config)# interface atm1/0
Router(config)# atm clock internal
Router(config-if)# atm pvp 100 l2transport
Router(config-atm-l2trans-pvc)# cell-packing 10 mcpt-timer 1
Router(config-if-vc)# vbr-nrt 3000 2000 200
Router(config-pmap-c)# service-policy output out_vbr-nrt
Router(config-atm-vc)# xconnect 2.2.2.2. 121 encapsulation mpls
Configuring AAL5 over MPLS on PVCs
This task illustrates the configuration of VBR-RT traffic shaping in AAL5 over MPLS VC mode.
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
DETAILED STEPS
Command or Action
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Cisco IOS Release 12.0(27)S
60
enable
configure terminal
policy-map policy-map-name
class class-default
queue-limit number-of-cells cells
exit
exit
interface atmslot/port
atm clock internal
pvc vpi/vci l2transport
encapsulation aal5
vbr-rt pcr scr burst
service-policy output policy-map-name
xconnect peer-router-id vcid encapsulation mpls
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Purpose
Enables privileged EXEC mode.
Enter your password if prompted.
•
Enters global configuration mode.
