How to Configure Layer 3 Terminated VCs on the 4-Port ATM ISE Line Card
CLP Bit Setting on a Per-Experimental Basis with VC Bundling
CLP bit setting can be combined with VC bundling by configuring VC bundling on a group of VCs as
desired, creating a policy map with CLP bit setting configured as desired, and then configuring the CLP
bit setting.
This example configures VC bundling and CLP bit setting on a per-experimental basis. There are two
VCs. Experimental 0 and 1 go to VC 1 with CLP on. Experimental 2 and 3 go to VC 1 with CLP off.
Experimental 4 and 5 go to VC 2 with CLP on, and experimental 6 and 7 go to VC 2 with CLP off. This
does not require a hierarchical policy, because there is only one queue per VC.
Note This example uses matching conditions based on the match mpls experimental command. This usage
causes CLP bits to be set based on the incoming MPLS experimental bits. You can just as easily use the
IP precedence bits to do this matching instead of the MPLS experimental bits.
class-map match-any exp01
match mpls experimental 0 1
class-map match-any exp45
match mpls experimental 4 5
policy set-clp-0145
class exp01
class exp45
interface atm4/0.1 point-to-point
ip address 4.0.1.1 255.255.255.0
bundle my-paris2-bundle
!
tag-switching ip
Troubleshooting Tips
To gather information on VC bundles so as to monitor them or to troubleshoot problems that pertain to
their configuration or use, use the following commands in privileged EXEC mode, as needed:
Command
Router# show atm bundle bundle-name
Router# show atm bundle bundle-name statistics
[detail]
Router# show atm map
Router# debug atm bundle adjacency events
Cisco IOS Release 12.0(27)S
34
set atm-clp
set atm-clp
pvc-bundle 40/1
precedence 0-3
service-policy output set-clp-0145
pvc-bundle 40/2
precedence 4-7
service-policy output set-clp-0145
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Purpose
Displays the bundle attributes assigned to each VC bundle
member and the current working status of the VC bundle
members.
Displays statistics or detailed statistics on the specified VC
bundle.
Displays a list of all configured ATM static maps to remote hosts
on an ATM network and on ATM bundle maps.
Displays information about ATM bundle adjacency change
events.
