Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Configuring Cell Packing over MPLS on PVCs
This task illustrates the configuration of VBR-RT traffic shaping in cell packing over MPLS VC mode.
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
DETAILED STEPS
Command or Action
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3
policy-map policy-map-name
Example:
Router(config)# policy-map out_vbr-rt
Step 4
class class-default
Example:
Router(config-pmap)# class class-default
enable
configure terminal
policy-map policy-map-name
class class-default
queue-limit number-of-cells cells
exit
exit
interface atmslot/port
atm clock internal
atm mcpt-timers timer1-timeout timer2-timeout timer3-timeout
pvc vpi/vci l2transport
encapsulation aal0
cell-packing cells mcpt-timer timer
vbr-rt pcr scr burst
service-policy output policy-map-name
xconnect peer-router-id vcid encapsulation mpls
How to Configure AToM VCs on the 4-Port ATM ISE Line Card
Purpose
Enables privileged EXEC mode.
Enter your password if prompted.
•
Enters global configuration mode.
Specifies the name of the service policy to configure with
the shaping queue size.
Specifies to configure the default class.
Cisco IOS Release 12.0(27)S
