How to Configure AToM VCs on the 4-Port ATM ISE Line Card
Command or Action
Step 12
vbr-rt pcr scr burst
Example:
Router(config-if-vc)# vbr-rt 10000 8000 256
Step 13
service-policy output policy-map-name
Example:
Router(config-pmap-c)# service-policy output
out_vbr-rt
Step 14
xconnect peer-router-id vcid encapsulation mpls
Example:
Router(config-atm-vc)# xconnect 2.2.2.2. 121
encapsulation mpls
Example
Router> enable
Router# configure terminal
Router(config)# policy-map out_vbr-rt
Troubleshooting Tips
Use the following show commands to display the cell relay and cell packing counters for troubleshooting
purposes:
Command
Router# show atm pvp
Router# show atm pvc
Router# show atm cell-packing
Router# show interface atmslot/port
Router# show mpls l2transport vc detail
Router# show tag alpha-atom atm port port-no vcid
vcid
