How to Configure AToM VCs on the 4-Port ATM ISE Line Card
Router# configure terminal
Router(config)# interface atm1/0
Router(config-if)# atm mcpt-timers 100 200 1000
Router(config-if)# pvc 0/100 l2transport
Router(config-atm-l2trans-pvc)# encapsulation aal0
Router(config-atm-l2trans-pvc)# cell-packing 10 mcpt-timer 1
Router(config-atm-l2trans-pvc)# xconnect 13.13.13.13 100 encapsulation mpls
Configuring ATM Cell Packing over MPLS on PVPs
Perform this task to configure ATM cell packing on permanent virtual paths (PVPs).
Restrictions
•
•
•
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
7.
DETAILED STEPS
Command
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3
interface atmslot/port
Example:
Router(config)# interface atm1/0
Cisco IOS Release 12.0(27)S
44
The cell packing function can only be configured when the ATM VP is configured for AAL0
encapsulation. It has no meaning if the VP is configured with AAL5 encapsulation.
In cell packing, only cells from the same VC/VP can be packed into one MPLS packet. Cells from
different connections cannot be concatenated into the same MPLS packet
The number of cells that can be packed varies from 2 to 28.
enable
configure terminal
interface atmslot/port
atm mcpt-timers [timer1-timeout timer2-timeout timer3-timeout]
atm pvp vpi l2transport
cell-packing cells mcpt-timer timer
xconnect peer-router-id vcid encapsulation mpls
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Purpose
Enables privileged EXEC mode.
Enter your password if prompted.
•
Enters global configuration mode.
Specifies an ATM interface.
