Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Command or Action
police bps burst-normal burst-max
conform-action action exceed-action action
Example:
Router(config-pmap-c)# police 8000 2000 4000
conform-action transmit exceed-action drop
priority
queue-limit cells cells
Example:
Router(config-pmap-c)# queue-limit 576 cells
random-detect
random-detect dscp-based
random-detect dscp dscpvalue min-threshold
cells max-threshold cells
[mark-probability-denominator]
Example:
Router(config-pmap-c)# random-detect dscp 1 300
cells 700 cells 1
random-detect precedence precedence
min-threshold cells max-threshold cells
[mark-prob-denominator
Example:
Router(config-pmap-c)# random-detect precedence
4 500 cells 1100 cells 1
random-detect exponential-weighting-constant n
Example:
Router(config-pmap-c)# random-detect
exponential-weighting-constant 1
set atm-clp
Purpose
Specifies a bandwidth usage and conformance policy by a traffic
class through the use of a token bucket algorithm. For a description
of the conform-action and exceed-action keywords, see
page 16.
Specifies the class as the priority class.
In order to specify the maximum bandwidth allowed by the priority
class, use the police command with the exceed-action set to drop. If
no maximum bandwidth is specified for the priority class, remaining
classes will not have a minimum bandwidth guarantee.
Specifies the maximum number of cells queued for a traffic class that
has a bandwidth configuration or class default specified.
Enables a weighted random early detection (WRED) drop policy for
a traffic class that has a bandwidth configuration or class default
specified.
Indicates that WRED is to use the DSCP value when it calculates the
drop probability for the packet.
Specifies the minimum and maximum cell thresholds and,
optionally, the mark-probability denominator for the DSCP value.
Use either the random-detect dscp-based command with
Note
the random-detect dscp command or use the
random-detect precedence command alone. Do not use the
random-detect precedence command with either of the
DSCP commands.
Specifies the minimum and maximum cell thresholds and,
optionally, the mark-probability denominator for the precedence
value.
Use either the random-detect dscp-based command with
Note
the random-detect dscp command or use the
random-detect precedence command alone. Do not use the
random-detect precedence command with either of the
DSCP commands.
Configures a WRED exponential weighting constant on a per COS
queue basis.
Sets the ATM cell loss priority bit to 1.
Configuring Modular QoS CLI
Table 5 on
Cisco IOS Release 12.0(27)S
