Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Command or Action
Step 4
pvc [name] vpi/vci
Example:
Router(config-if)# pvc 0/100
Step 5
cbr pcr
Router(config-if-vc)# cbr 155000
Step 6
vbr-rt pcr scr burst
Example:
Router(config-if-vc)# vbr-rt 100000 40000
200000
Step 7
vbr-nrt pcr scr mbs
Example:
Router(config-if-vc)# vbr-nrt 100000 40000
200000
Step 8
ubr pcr
Example:
Router(config-if-vc)# ubr 100000
Configuring OAM Management on Terminated VCs
OAM may be enabled for PVC or SVC management on terminated VCs. To configure OAM management
for an ATM Layer 3 PVC, perform the following procedure.
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
7.
8.
enable
configure terminal
interface atmslot/port.subinterface [point-to-point | multipoint]
pvc vpi/vci
oam-pvc manage
oam retry up-count down-count retry-frequency
oam-pvc manage cc {end | segment} [direction {both | sink | source}] [keep-vc-up [end aisrdi
failure | seg aisrdi failure]]
oam retry cc {end | segment} [activation-count [deactivation-count [retry-frequency]]]
How to Configure Layer 3 Terminated VCs on the 4-Port ATM ISE Line Card
Purpose
Specifies a PVC with the specified VPI and virtual circuit
identifier (VCI).
Specifies CBR shaping.
The pcr value indicates the peak cell rate. The range is from
38 to 622,000 Kbps.
Use either Step 5,
Note
Specifies VBR-rt shaping.
The pcr value indicates the peak cell rate, and its range is
from 38 to 622,000 Kbps. The scr value indicates the
sustainable cell rate, and its range is from 38 to pcr Kbps.
The burst value indicates the burst size, in number of cells.
Specifies VBR-nrt shaping.
The pcr value indicates the peak cell rate, and its range is
from 38 to 622,000 Kbps. The scr value indicates the
sustainable cell rate, and its range is from 38 to pcr Kbps.
The mbs value indicates the maximum burst size, in number
of cells.
Specifies UBR shaping.
The pcr value indicates the peak cell rate, and its range is
from 38 to 622,000 Kbps.
Cisco IOS Release 12.0(27)S
Step 6, Step 7, or Step 8.
