Configuration Basics

After you verify that the new 4-Port ATM ISE line card is installed correctly, use the configure command
to configure the new interface. Be prepared with the information that you will need, such as the interface
IP address.
The Cisco 12000 Series Router identifies an interface address by its line card slot number and port
number, in the format slot/port. Because each 4-Port ATM ISE line card contains four ATM interfaces,
the port numbers are 0 to 3. For example, the slot/port address of an ATM interface on a 4-Port ATM ISE
line card installed in line card slot 2 is 2/0 to 2/3.
Use the following procedure to create a basic configuration, including enabling an interface and
specifying IP routing. You might also need to enter other configuration subcommands, depending on the
requirements for your system configuration.
(For descriptions of configuration subcommands and the configuration options available, refer to the
appropriate software publications in the
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
7.
8.
DETAILED STEPS
Command or Action
Step 1
show version
Step 2
show interfaces
Step 3
enable
Example:
Router> enable
Step 4
configure terminal
Example:
Router# configure terminal
Step 5
interface atmslot/port
Example:
Router(config)# interface atm1/3
Cisco IOS Release 12.0(27)S
6
show version
show interfaces
enable
configure terminal
interface atmslot/port
no shutdown
Ctrl-Z
copy running-config startup-config
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
"Related Documents" section on page
Purpose
Confirm that the system recognizes the line card.
Check the status of each port on the line card.
Enables privileged EXEC mode.
• Enter your password if prompted.
Enters global configuration mode.
Enter interface configuration mode for the specified ATM
interface.
91.)
