Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Command
Router# debug atm bundle errors
Router# debug atm bundle events
Configuring Bridged PVCs
The purpose of bridged permanent virtual circuits (BPVCs) is to allow ATM interfaces in the Cisco
high-end router to be used in an edge or aggregation role and connect to a Cisco Catalyst switch or to
another remote device that supports bridged-format RFC 1483 PDUs only.
Note Only Ethernet frames using Ethernet v2 format are supported. IEEE 802.3 format is not supported.
To create a BPVC, perform the following steps:
Command
Step 1
Router(config)# interface atm 1/0.4
multipoint
Step 2
Router(config-subif)# pvc 3/45
Step 3
Router(config-if-atm-vc)# encapsulation
aal5snap bridge
Only one bridged PVC is allowed for each ATM subinterface.
Note

How to Configure AToM VCs on the 4-Port ATM ISE Line Card

This section describes how to configure AToM VCs in the following tasks:
•
•
•
•
•
Configuring Layer 2 AToM Virtual Circuits
A virtual circuit (VC) is a point-to-point connection between two ATM devices. A VC is established for
each ATM end node with which the router communicates. Permanent virtual circuits (PVCs) configured
on the router remain active until the circuit is removed from the configuration. All virtual circuit
characteristics apply to PVCs. When a PVC is configured, all configuration options are passed to the
4-Port ATM ISE line card. These PVCs are written to the nonvolatile RAM (NVRAM) as part of the
configuration and are used when the Cisco IOS image is reloaded.
Configuring Layer 2 AToM Virtual Circuits, page 35
Configuring AToM VCs, page 36
Configuring ATM Shaping on AToM VCs, page 49
Configuring Cell-Based Traffic Policing on AToM VCs, page 63
Configuring Experimental Mapping, page 73
How to Configure AToM VCs on the 4-Port ATM ISE Line Card
Purpose
Displays information on bundle errors.
Displays a record of bundle events.
Purpose
Create a multipoint subinterface.
Create a PVC.
Configure the encapsulation type to "aal5snap bridge".
Cisco IOS Release 12.0(27)S
35
