Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers

•

How to Perform a Basic Configuration of the 4-Port ATM ISE Line

Card

The 4-port ATM ISE line cards provide the ability to configure Layer 2 AToM VCs as well as Layer 3

terminated VCs. On any individual ATM interface, you can configure both AToM VCs and terminated

VCs as required. The configurations of these are discussed in subsequent sections in this document. This

section provides basic ATM interface configuration information and discusses those features that are

applicable to both AToM VCs and terminated VCs.

Configuring ATM interfaces and virtual circuits is described in the following sections:

•

Configuring an ATM Interface

Use the show running-config command to display current port configuration information. On power up,

the interface on a new 4-Port ATM ISE line card is shut down. To enable the interface, you must enter a

no shutdown command in configuration mode.

Default Interface Configuration

When the 4-Port ATM ISE line card is enabled (taken out of shutdown) with no additional configuration

commands applied, the default interface configuration file parameters, described in

Table 3

Parameter

Maximum transmission unit (MTU)

Maximum numbers of virtual circuits

Loopback

Internal clock

SONET framing

2. Subject to overall system limitation and configuration.

Any Transport over Multiprotocol Label Switching (MPLS) [AToM].

ATM OAM Emulation

Cell-based policing

Experimental bit marking

Cell packing for port, VC, and VP modes

Cell relay for port, VC, and VP modes

Configuring an ATM Interface, page 5

Configuring UNI and NNI Cell Support, page 7

Troubleshooting Tips, page 7

4-Port ATM ISE Line Card Default Configuration Values
