How to Configure Layer 3 Terminated VCs on the 4-Port ATM ISE Line Card
Command
Router(config-vc-class)# vbr-rt pcr scr [mbs]
Router(config-vc-class)# cbr [pcr]
Applying a VC Class to a Discrete VC Bundle Member
To attach a preconfigured VC class containing bundle-level commands to a bundle member, use the
following command in bundle-vc configuration mode:
Command
Router(config-if-atm-member)# class-vc vc-class-name
Parameters that configure a VC that are contained in a VC class assigned to that VC are superseded by
parameters that are directly configured for the VC through discrete commands entered in bundle-vc
configuration mode.
Configuring a VC Not to Accept Bumped Traffic
To configure an individual VC bundle member not to accept traffic that otherwise might be directed to
it if the original VC carrying the traffic goes down, use the following command in bundle-vc
configuration mode:
Command
Router(config-if-atm-member)# no bump traffic

VC Bundle Examples

•
•
•
•
VC Bundle Configuration on an IP Subinterface Example
This example configures a VC bundle with eight member VCs on an IP subinterface.
interface ATM5/0.2 point-to-point
ip address 1.5.0.1 255.255.255.0
no ip directed-broadcast
no atm enable-ilmi-trap
bundle b502
pvc-bundle 1/107
precedence 7
pvc-bundle 1/106
precedence 6
Cisco IOS Release 12.0(27)S
32
VC Bundle Configuration on an IP Subinterface Example, page 32
VC Bundle Configuration Using MPLS and Service Policies Example, page 33
VC Bundle Configuration Using a VC Class Example, page 33
CLP Bit Setting on a Per-Experimental Basis with VC Bundling, page 34
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Purpose
Configures VBR-RT as the traffic shaping rule for the VC,
qualified by peak cell rate (pcr), sustainable cell rate (scr), and
optional maximum burst cell size (mbs).
Configures UBR as the traffic shaping rule for the VC, qualified
by an optional peak cell rate (pcr).
Purpose
Assigns a VC class to a VC bundle member.
Purpose
Configures the VC not to accept any bumped traffic that would
otherwise be redirected to it.
