Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Command or Action
Step 10
exit
Example:
Router(config-pmap)# exit
Step 11
policy-map vbr2
Example:
Router(config)# policy-map vbr2
Step 12
class class-default
Example:
Router(config-pmap)# class class-default
Step 13
set mpls experimental mpls-exp-value
Example:
Router(config-pmap-c)# set mpls experimental 4
Step 14
police rate pcr cps delay-tolerance cdvt
conform-action transmit exceed-action drop
Example:
Router(config-pmap-c)# police rate 2500000 cps
delay-tolerance 10 conform-action transmit
exceed-action drop
Step 15
service-policy child-vbr2
Example:
Router(config-pmap-c)# service-policy
child-vbr2
After you configure the policy map, you must attach it to a PVC using the service-policy command as
described in the
Configuring VBR.3 Policing
This task describes how to configure VBR.2 policing.
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
"Attaching a Service Policy to a PVC" section on page
enable
configure terminal
class-map match-all clp0
match not atm clp
exit
policy-map child-vbr3
How to Configure AToM VCs on the 4-Port ATM ISE Line Card
Purpose
Exits policy map mode.
Specifies the name of the parent service policy to configure.
Specifies to configure the default class.
(Optional) Specifies the value used to set the MPLS EXP
bits defined by the policy map. Valid values are numbers
from 0 to 7.
Specifies a maximum bandwidth usage by a traffic class
through the use of a token bucket algorithm. For a
description of the conform-action and exceed-action
keywords, see Table 5 on page
Attaches the child service policy to the VBR1 policy map.
Cisco IOS Release 12.0(27)S
16.
72.
