Cisco ISE - Line Card ISE Configuration Manual page 66

How to Configure AToM VCs on the 4-Port ATM ISE Line Card
DETAILED STEPS
Command or Action
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3
policy-map child-vbr1
Example:
Router(config)# policy-map child-vbr1
Step 4
class class-default
Example:
Router(config-pmap)# class class-default
Step 5
police rate scr cps atm-mbs mbs cells
conform-action transmit exceed-action drop
Example:
Router(config-pmap-c)# police rate 200000 cps
atm-mbs 1024 cells conform-action transmit
exceed-action drop
Step 6
exit
Example:
Router(config-pmap-c)# exit
Step 7
exit
Example:
Router(config-pmap)# exit
Step 8
policy-map vbr1
Example:
Router(config)# policy-map vbr1
Step 9
class class-default
Example:
Router(config-pmap)# class class-default
Cisco IOS Release 12.0(27)S
66
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Purpose
Enables privileged EXEC mode.
Enter your password if prompted.
•
Enters global configuration mode.
Specifies the name of the child service policy to configure.
Specifies to configure the default class referred to as
class-default.
Specifies a maximum bandwidth usage by a traffic class
through the use of a token bucket algorithm. For a
description of the conform-action and exceed-action
keywords, see Table 5 on page
Exits class mode.
Exits policy-map mode.
Specifies the name of the parent service policy to configure.
Specifies to configure the default class.
16.
