Troubleshooting ATM Errors on the 4-Port ATM ISE Line Card

Command or Action
Step 3
policy-map policy-map-name
Example:
Router(config)# policy-map atm-policy
Step 4
class class-map-name
Example:
Router(config-pmap)# class atm-class
Step 5
set mpls experimental mpls-exp-value
Example:
Router(config-pmap-c)# set mpls experimental 4
Step 6
exit
Example:
Router(config-pmap-c)# exit
Step 7
exit
Example:
Router(config-pmap)# exit
Step 8
interface atmslot/port
Example:
Router(config)# interface atm1/0
Step 9
service-policy input policy-map-name
Example:
Router(config-if)# service-policy input
atm-policy
Step 10
xconnect peer-router-id vcid encapsulation mpls
Example:
Router(config-atm-l2trans-pvc)# xconnect
13.13.13.13 100 encapsulation mpls
Troubleshooting ATM Errors on the 4-Port ATM ISE Line Card
The following sections provide information to help you troubleshoot ATM errors on the 4-port ATM ISE
line cards:
•
•
•
Cisco IOS Release 12.0(27)S
76
Troubleshooting Commands, page 77
Obtaining Per-VC Counters, page 81
Debugging Unexpected TX Drops on a VC, page 82
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Purpose
Specifies the name of the child service policy to configure.
Specifies to configure the default class referred to as
class-default.
(Optional) Specifies the value used to set the MPLS EXP
bits defined by the policy map. Valid values are numbers
from 0 to 7.
Exits class mode.
Exits policy-map mode.
Specifies an ATM interface to configure.
Attaches a service policy to a VC and specifies the direction
in which the policy should be applied.
Binds the attachment circuit to a pseudowire VC or VP.
