How to Configure AToM VCs on the 4-Port ATM ISE Line Card
7.
8.
9.
10.
11.
12.
13.
14.
15.
DETAILED STEPS
Command or Action
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3
class-map match-all class-map-name
Example:
Router(config)# class-map match-all cpl0
Step 4
match not match-criteria
Example:
Router(config-cmap)# match not atm clp
Step 5
exit
Example:
Router(config-cmap)# exit
Step 6
policy-map child-vbr3
Example:
Router(config)# policy-map child-vbr1
Step 7
class class-map-name
Example:
Router(config-pmap)# class clp0
Cisco IOS Release 12.0(27)S
70
class clp0
police rate scr cps atm-mbs mbs cells conform-action transmit exceed-action transmit
exit
exit
policy-map vbr3
class class-default
set mpls experimental mpls-exp-value
policy rate pcr cps delay-tolerance cdvt conform-action transmit exceed-action drop
service-policy child-vbr3
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Purpose
Enables privileged EXEC mode.
Enter your password if prompted.
•
Enters global configuration mode.
Specifies the user-defined name of the traffic class. Use
match-all to specify a logical AND operator for all
matching statements under this traffic class.
Specifies a single match criterion value to use as an
unsuccessful match criterion.
Exits class-map mode.
Specifies the name of the child service policy to configure.
Specifies to configure the class defined in Step 3.
