Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Command or Action
Step 14
vbr-rt pcr scr burst
Example:
Router(config-if-vc)# vbr-rt 2000 1000 100
Step 15
service-policy output policy-map-name
Example:
Router(config-pmap-c)# service-policy output
out_vbr-rt
Step 16
xconnect peer-router-id vcid encapsulation mpls
Example:
Router(config-atm-vc)# xconnect 2.2.2.2. 121
encapsulation mpls
Example
Router> enable
Router# configure terminal
Router(config)# policy-map out_vbr-rt
Router(config-pmap)# class class-default
Router(config-pmap-c)# queue-limit 300 cells
Router(config-pmap-c)# exit
Router(config-pmap)# exit
Router(config)# interface atm1/0
Router(config)# atm clock internal
Router(config-if)# atm mcpt-timers 100 1000 5000
Router(config-if)# pvc 21/21 l2transport
Router(config-atm-l2trans-pvc)# encapsulation aal0
Router(config-atm-l2trans-pvc)# cell-packing 10 mcpt-timer 1
Router(config-if-vc)# vbr-rt 2000 1000 100
Router(config-pmap-c)# service-policy output out_vbr-rt
Router(config-atm-vc)# xconnect 2.2.2.2. 121 encapsulation mpls
Configuring Cell Packing over MPLS on PVPs
The following task illustrates the configuration of VBR-NRT traffic shaping in cell packing over MPLS
in VP mode:
SUMMARY STEPS
1.
2.
3.
enable
configure terminal
policy-map policy-map-name
How to Configure AToM VCs on the 4-Port ATM ISE Line Card
Purpose
Specifies VBR-rt shaping.
The pcr value indicates the peak cell rate, and its range is
from 38 to 622000 Kbps. The scr value indicates the
sustainable cell rate, and its range is from 38 to pcr Kbps.
The burst value indicates the burst size, in number of cells.
In place of the vbr-rt command, you can use the
Note
ubr, cbr, or vbr-nrt commands to configure UBR,
CBR, or VBR-nrt shaping in the same way.
Attaches the queue-limit service policy to the PVC.
Binds the attachment circuit to a pseudowire VC.
