How to Configure AToM VCs on the 4-Port ATM ISE Line Card
Router(config-atm-l2trans-pvc)# xconnect 13.13.13.13 100 encapsulation mpls
Configuring ATM Cell Relay over MPLS on PVPs
Perform this task to configure ATM Cell Relay on permanent virtual paths (PVPs).
Restrictions
The cell relay function can only be configured when the ATM VP is configured for AAL0 encapsulation.
It has no meaning if the VP is configured with AAL5 encapsulation.
SUMMARY STEPS
1.
2.
3.
4.
5.
DETAILED STEPS
Command
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3
interface atmslot/port
Example:
Router(config)# interface atm1/0
Step 4
atm pvp vpi l2transport
Example:
Router(config-if)# atm pvp vpi 1
l2transport
Step 5
xconnect peer-router-id vcid encapsulation
mpls
Example:
Router(config-atm-l2trans-pvc)# xconnect
13.13.13.13 100 encapsulation mpls
Cisco IOS Release 12.0(27)S
40
enable
configure terminal
interface atmslot/port
atm pvp vpi l2transport
xconnect peer-router-id vcid encapsulation mpls
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Purpose
Enables privileged EXEC mode.
Enter your password if prompted.
•
Enters global configuration mode.
Specifies an ATM interface.
Specifies that the PVP is dedicated to transporting ATM cells. The
l2transport keyword indicates that the PVC is a switched PVC
and not a terminated PVC.
Binds the attachment circuit to a pseudowire VC or VP.
